Outdoor All In One Solar Led Street Lights – Solar Energy Lighting

Product Parameters:

Wattage: 30W, 40W, 60W, 80W, 100W, 120W
Luminous Efficacy: 180LM/W
Lumen Output: 5400lm-21600lm
Warranty: 3 years
Waterproof: IP65

Product Details

Datasheet

Model	HS-SSL-30W	HS-SSL-40W	HS-SSL-60W	HS-SSL-80W	HS-SSL-100W	HS-SSL-120W
Solar Panel	6V, 30W	6V, 40W	6V, 42W	6V, 50W	6V, 55W	6V, 65W
Lithium Battery	80WH,3.2V	116WH,3.2V	144WH,3.2V	192WH,3.2V	240WH,3.2V	288WH,3.2V
CCT	2700-6500K
Lumen Efficiency	180LPW
Charging Time	6-8 hours
Working Time	12-15 hours(5-7 rainy days)
Control Mode	Time control+Microwave induction or Infrared induction
IP Rating	IP66
Mounting Height	4-6 meters5-7 meters		5-7 meters	6-8 meters	9-10 meters	10-11meters
Installing Space Between 2 Lamps	10-22 meters
Warranty	5 years
Product Size(mm)	697361209		846361209		1096361209
Net Weight(KG)	7	7.7	9	9.5	11	11.7

Features

1. Mainstream integrated structured design, saving transportation costs.
2. Bridgelux chips 3030 (Lifetime 100000 hours).
3. imported high-efficiency monocrystalline silicon.
4. The whole lamp can be 30′ adjustable.
5. Built-in large-capacity LifePO4 battery
6. The beam angle is 70°140″, Asymmetric 30.
7. Easy to install and disassemble, convenient maintenance.
8. With 4 lighting modes, flexible to switch via remote control.
9. Remote control distance of up to 15 meters.

Why Choose Hishine All-In-One Solar Light?


130 Induction angle, 10m Induction distance.	High brightness 3030 chips, lifetime 100000 hours.	Solar panel, >21% photoelectric conversion rate.	Made of ADC12 aluminum die-casting


Multifunctional microwave induction	Multi-working modes	IP66, Lamp with silicone waterproof sealing strip

Outdoor All In One Solar Led Street Lights – Solar Energy Lighting插图7

High charging efficiency controller
It can automatically adjust the output power according to weather changes.

Lithium battery
Can work at temperatures from-20’c to +55°c
>2000 cyclesLithium iron phosphate(LifePO4) battery

Packing Size of All-In-One Solar Street Light

Mounting Hole Size of All-In-One Solar Street Light

Applications

1. Highway: Hi-Small LED solar street light provides powerful light efficacy and an independent heat dissipation system, with an intelligent control system（LoRa/DALI/ZigBee…）, it can be easily managed without leaving the center room.

2. Urban Roads: A sleek and modern design that blends well with contemporary urban environments. They are also compact and lightweight, making them easy to install and maintain.

3. Outdoor Way & Parking Lot: Hi-Small LED solar street light is equipped with advanced sensors and controls that allow for remote monitoring and adjustment of lighting levels. This ensures that energy is not wasted by lighting areas that are not in use and that the lighting is optimized for maximum efficiency.

Hot Tags: Economical LED Solar Street Light | MPPT Controller, manufacturers China, suppliers China, factory, wholesale, buy, Round Led Retrofits, led retrofit lamps, led can light retrofit, Panel High Bay Light, Flat Panel High Bay Light, Endless Connection High Bay.

Hishine Group Limited is a leading manufacturer in the industry of LED lights, specializing in the production of high-quality solar LED lights, including solar street lights, lawn lights, and floodlights.
